Thailand 4x4 pickup SUV exporter importer of RHD LHD New 2017 and Used Toyota Revo, Toyota Vigo, Toyota Fortuner, L200 Triton, and Nissan Navara
Sam Motors Thailand is proud to be Thailand's best exporter of Extra Cab Toyota Hilux Vigo while our parent company Sam Auto Group Thailand is Thailand's best exporter of nearly new or quality used Extra Cab Toyota Hilux Vigo or Toyota Hilux Tiger. Please note that it is Extra Cab and not Extra Cap as some misspell it. Click here for info on 2009 Toyota Hilux Vigo and click here for the main Vigo page. Pics of some of the vehicles we have recently exported are at http://www.sam4x4.com/pics.html. We are not only Thailand's best Vigo dealer and Thailand's best Vigo exporter of Toyota Hilux Vigo 4x4 but also Toyota Hilux parts and Toyota Hilux accessories. Please try Sam - Thailand's best Vigo pickup exporter. If you are looking for Toyota Hilux, Toyota Hilux D4D diesel, Toyota Hilux 4x4 Vigo or Toyota Hilux mini truck for sale it good to know that Toyota Hilux Vigo is always on sale at Sam Motors Thailand. If you are looking for best quality used Toyota Hilux Tiger and D4D Toyota Hilux Sport Cruiser, Sam is the place.
Email us now at thai4x4@gmail.com for your very own Toyota Vigo or Toyota Hilux Tiger.
Grade |
3.0 G
|
3.0 E
|
2.5 E
|
Model Code |
KUN26R-CRMSYT
( AN ) |
KUN26R-CRMSYT
( AM ) |
KUN25R-CRMSHT
( AJ ) |
Size and Weight | |||
Outside dimension mm. |
5130 x 1795 x 1810 ( L x W x H )
|
||
Wheel length mm. |
3085
|
||
Wheel width mm. |
1540 x 1540 ( Front / Back wheel )
|
||
Ground clearance mm. |
212
|
||
Tray interior mm. |
1515 x 1805 x 450 ( W x L x H )
|
||
Interior mm. |
1475 x 1840 x 1190 ( W x L x H )
|
||
Weight (approximately) kg. |
1550
|
1540
|
|
Engine | |||
Engine model
|
1KD FTV
|
2KD-FTV ( I/C )
|
|
Engine type
|
4 Cylinder DOHC 16 valve variable
nozzle turbo & intercooler |
4 Cylinder DOHC 16 valve
turbo & intercooler |
|
Displacement cc.
|
2982
|
2494
|
|
Bore x Stroke mm.
|
97.0 x 103.0
|
92.0 x 93.8
|
|
Compression ratio
|
17.9 : 1
|
18.5 : 1
|
|
Max output (SAE net) kw(EEC net)/rpm
|
120 ( 163 ) / 3400
|
88 ( 120 ) / 3600
|
|
Max torque (SAE net ) (N-m)/rpm
|
343 / 1400 - 3200
|
320 / 2000
|
|
Fuel providing system |
Direct Injection Commonrail type
|
||
Fuel tank capacity litre |
76
|
||
Emission Standard |
Euro 3
|
||
Chassis | |||
Driving system |
5 speed manual
|
||
Gear ratio : 1 |
4.313
|
||
: 2 |
2.330
|
||
: 3 |
1.436
|
||
: 4 |
1.000
|
||
: 5 |
0.838
|
||
Reverse |
4.220
|
||
Final gear ratio Per 1 |
3.583
|
3.909
|
|
Suspension Front |
Independent-wishbone, torsion bar with stabilizer and automatic
cutout ( A.D.D. )
|
||
Back |
Rigid-elliptic leaf springs with limited slip
|
||
Brake Front |
Ventilated Discs
|
||
Back |
Drum with brake oil valve SUPER LSPV with LTS
|
||
Power Steering |
Power assisted Rack and Pinion
|
||
Min. turning radius m. |
6.2
|
||
Tyre |
255 / 70R15C
|
||
Wheel |
Alloy wheel size 7JJ x 15
|
||
General equipment
|
|||
Exterior | |||
Bumper bar | Body Coloured | ||
Front grill | Body Coloured with Chrome | ||
Front light | Halogen multi reflector | ||
Door mirrors | Chrome Electronically Adjustable | ||
Mud flaps | Only 2 wheels at back side | ||
Door handles ( Grip Type ) | Chrome | ||
Wiper | Time Setting | ||
Interior | |||
Instrument panel: | |||
Tachometer | |||
Kilometer |
Digital
|
||
Warning signal : | |||
Fuel level
|
|||
Oil filter light
|
|||
Headlight- turn off
warning sound |
|||
Key warning sound
|
|||
Door-closed warning light
|
|||
Seat-belt warning light
|
On driver side
|
||
Interior lights : | |||
Ashtray
|
With Light
|
||
Rear mirror
|
Reduction of light -reflecting
|
||
Audio : | |||
Radio-cassette
|
|||
Speakers
|
4
|
||
Antenna
|
Front position
|
||
Steering wheel Adjustable |
Urithene 4 spokes
|
||
Type
|
Urithene 4 spokes
|
Urithene 3 spokes
|
|
Hand brake |
at center console
|
||
Sun visor : | |||
Driver side
|
With name card keeper
|
||
Passenger side
|
With small mirror
|
||
Power windows |
|
||
Central lock | |||
Key remote |
|
||
Alarm system and key immobilzer |
|
||
Power socket | 1 Socket 12 Voltages | ||
Interior handles | 3 positions at front | ||
Door console : | |||
Type
|
Standard
|
||
Material
|
Velvet
|
||
Arm rest
|
Front
|
||
Seats :
|
Separated type
|
||
Type
|
Separated type
|
||
Material
|
Velvet creamy colour
|
||
Front seats : Adjustable
|
With walk-in system
|
||
Backward adjusting
|
|||
Height level adjusting
|
|||
Pillow
|
|||
Back seats : Type |
|
||
Pillow
|
|
||
Fuel cap release | |||
Glove box : | |||
Center console
|
With cover
|
||
best console
|
|||
Bottom console
|
With key
|
||
Sun glass box
|
Same position of light map
|
||
Door console
|
2 doors with bottle holder
|
||
Cup holder : |
2 positions at front console
1 position at center console |
||
With key
|
|||
With bottle holder
|
|||
Cup holder : |
2 positions at front console
|
||
Foot rest | |||
Active Safety | |||
ABS |
|
||
Third brake light |
|
||
Fog lights |
|
||
Heated rear windscreen |
|
||
Interior door locking |
|
||
Passive Safety | |||
GOA Body | |||
Side racks | |||
Windscreen |
Safety glass
|
||
Air bag | Only driver side |
|
|
Seat belts | |||
Front seats
|
ELR 3 points 2 positions
|
||
Rear seats
|
|
||
Adjustable
|
Front passenger seat and drive seat
|
||
Collision protection body | |||
Collapsable steering wheel | |||
Side impact protection | |||
Automatic oil valve cutting | |||
Extra Equipments | |||
Air-con |
With control switch rotate-type
|
||
Audio 1 CD with MP3 |
|
||
Rear bumper |
Chrome
|
||
Wheel arch |
Body coloured
|
||
Side step | |||
Fog lights |
|
Remarks := Not Available
|
|
|
Model : |
Hilux Vigo Extra Cab 3.0 G |
Hilux Vigo Extra Cab 3.0 E |
Engine Type : |
1KD-FTV Inline 4 DOHC VN Turbo Intercooler |
2KD-FTV Inline 4 DOHC VN Turbo Intercooler |
Engine Capacity : |
2982 |
2982 |
Style : |
Extra Cab |
Extra Cab |
Driving System : |
2WD |
2WD |
Transmission : |
Manual 5 Speed |
Manual 5 Speed |
Model : | Hilux Vigo Extra Cab 2.5 G | Hilux Vigo Extra Cab 2.5 E | Hilux Vigo Extra Cab 2.5 J-PS | Hilux Vigo Extra Cab 2.5 J- |
Engine Type : | 2KD-FTV Inline 4 DOHC VN Turbo | 2KD-FTV Inline 4 DOHC VN Turbo | 2KD-FTV Inline 4 DOHC VN Turbo | 2KD-FTV Inline 4 DOHC VN Turbo |
Engine Capacity : | 2494 | 2494 | 2494 | 2494 |
Style : | Extra Cab | Extra Cab | Extra Cab | Extra Cab |
Driving System : | 2WD | 2WD | 2WD | 2WD |
Transmission : | Manual 5 Speed | Manual 5 Speed | Manual 5 Speed | Manual 5 Speed |
